Industrial wireless router series products are a kind of Internet of Things communication equipment for remote data acquisition and remote monitoring, widely used in power system, industrial monitoring, traffic management, weather monitoring, water dispatching, environmental monitoring, coal and oil and other industrial fields, is one of the essential key equipment in the development of industrial Internet of things. To provide users with convenient, fast and efficient device networking solutions. Moving Star industrial wireless router adopts high-end core chip design scheme, stable communication, reliable performance, powerful function, superior industrial protection ability, especially suitable for harsh industrial environment.
● Support 2.4G+5G dual-frequency WLAN wireless LAN, support LED status monitoring
● Support routing, AP, relay, universal bridge and client five working modes
● Support user isolation and adjustable transmit power, support country code setting
● Support virtual SSID and SSID hiding, support VPN, peanut shell intranet penetration
● Industrial-grade design, EMC level 4 protection, rail mounting, stable and reliable
Electrical port parameters | |
Interface standard | Comply with IEEE802.3 standard |
Interface | 4 LAN ports, 1 WAN port |
Features | RJ-45 shielded port supports 10Base-T/100Base-TX, supports auto-negotiation function |
Transmission distance | <100 meters |
Wi-Fi Parameters | |
Frequency | Frequency range: 2412GHz---2484MHz |
Transmit power | IEEE 802.11n: 13-16dBm @HT20/40 MCS7 |
IEEE 802.11g: 14-17dBm @54MHz | |
IEEE 802.11b: 16-20dBm @11MHz | |
Receiving sensitivity | HT40 MCS7: -69dBm@10% PER(MCS7) |
HT20 MCS7: -71dBm@10% PER(MCS7) | |
54M: -75dBm@10% PER | |
11M: -88dBm@ 8% PER | |
Antenna parameters | |
Standard | Support 802.11b/g/n |
Quantity | 2 pcs |
Interface | SMA interface (outer screw inner hole) |
Power parameters | |
power supply | DC9-36V |
Power consumption | <2.5W |
Overcurrent protection | Built-in |
Temperature | |
Operating temperature | -40℃～70℃ |
Storage temperature | -40～85℃ |
Humidity | 5%～95% RH (non-condensing) |
Mechanical parameters | |
Physical size | (Height×Width×Depth): 118mm×35mm×86mm (not including DIN rail assembly size) |
Installation method | DIN rail type |
Heat dissipation form | Aluminum alloy single-rib chassis surface heat dissipation, no fan |
Weight | 0.3kg |
Industry Standard | |
EMC | EN61000-4-2(ESD), Level 4 |
EN61000-4-4(EFT), Level 4 | |
EN61000-4-5(Surge), Level 4 | |
Shock | IEC60068-2-27 |
Free fall | IEC60068-2-32 |
Shock | IEC60068-2-6 |
