The Star shifting interface converter products include three major series:
Industrial serial optical fiber converter can convert the industrial site RS232/485/422 serial electrical signal into optical fiber signal transmission, to achieve long-distance transmission requirements, improve signal anti-interference ability;
Industrial serial cable converter, to achieve the industrial site RS232 and RS485/422 signals between the conversion, as well as multiple serial bus concentrator function, provide active/passive, isolated/non-isolated and other types of choice;
Industrial serial port repeater can realize the isolation relay function of RS232/485/422 signal in industrial field. By isolating and amplifies the signal, it can extend the communication distance and anti-interference.
● RS485 and TTL level bi-directional interconversion
● Isolated design, 2.5KV optoelectronic isolation
● Unique serial port protection circuit, can be powered hot-swappable
● Intelligent flow control, zero delay automatic forwarding
● Signal line 600W/ms lightning protection and 15KV anti-static protection
Technical Parameters | |
Protocol Standard | IEEE802.3(Ethernet), IEEE802.3u(100Base-TX&100Base-FX), IEEE802.3x (Flow control), IEEE802.3z(1000Base-LX)I, EEE802.3ab(1000Base-T) |
Switch Capability | |
MAC Table Size | 1k |
Switch Bandwidth | 14Gbps |
Switch Latency | <5μs |
Interface | |
Gigabit port | Number: 6 |
Connector: SFP Gigabit port(LC interface, single/multi-mode optional) or Gigabit RJ45 port | |
Baud rate: 1000Base-FX(SFP), auto-negotiation 10/100M-TX | |
Terminal block for relay alarm | 5.08mm terminal block, 1A@24VDC |
Terminal block for power input | 5.08mm terminal block |
Communication Distance | |
Twisted-pair | 100m(CAT5/CAT5e cable) |
Multi-mode fiber | Gigabit multi-mode: 850nm, 550m |
Single mode fiber | Gigabit single mode: 1310nm, 20km |
LED Indicator Lights | |
Front panel LED lights | Port light: LINK/ACT; SPEED |
Power status light: PWR1; PWR2 | |
Power | |
Input power | DC9-60V AD220V |
Power consumption | <3.5W@(MAX) |
Overload protection | support |
Inversed protection | support |
Working Environment | |
Operating temperature | -40°C~85°C |
Storage temperature | -45°C~85°C |
Ambient humidity | 5%~95% |
Physical Characteristics | |
Shell | IP40 protection, aluminum alloy shell |
Installation | Standard 35mm DIN-rail Mounting |
Dimension | 35mm*140mm*100mm |
Industry Standard | |
EMC | EN61000-4-2(ESD), Level 4 EN61000-4-3(RS), Level 4 EN61000-4-4(EFT), Level 4 EN61000-4-5(Surge), Level 4 EN61000-4-6(CS), Level 4 EN61000-4-8, Level 5 |
Impact | IEC60068–2-27 |
Falling | IEC60068-2-32 |
Shock | IEC60068-2-6 |
Warranty | |
Warranty | 5 Years |
Certification | CE, FCC, RoHS |
