USR-LG210 is a dual-channel LoRa gateway, which is connected to private servers, manned clouds, and Alibaba Cloud through 4G/Ethernet, and communicates with nodes (WH-L101-L-H20 module/USR-LG206-L-H20 data transmission terminal/USR-DR216-L rail data transmission terminal) through internal LoRa dual channels.
Project | Description | |
Wired network port | Wired WAN port | WAN * 1 |
LoRa | Agreement | Private Protocols |
Band | 410MHz~510MHz, a total of 113 channels | |
Passage | Dual data channels | |
Transmit power | 24dBm~30dBm | |
Antenna | Default Suction Cup Antenna (470MHz) | |
RS232/485 | Baud rate | 2400bps~230400bps |
Keystroke | Reload | One-click factory reset, firmware upgrade |
Set | obligate | |
Light | Status indicator | Power supply, Work indication, LoRa data transceiver and receiving |
Temperature | Operating temperature | USR-LG210-L-10 : -40℃ ~ +85℃ USR-LG210-L-42 : -20℃ ~ +70℃ |
Storage temperature | -40℃ ~ +125℃ | |
Humidity | Operating humidity | 5%~95%RH (no condensation) |
Store humidity | 1%~95%RH (no condensation) | |
Power supply | Supply voltage | DC9~36V |
Operating Current (Max) | USR-LG210-L-10: 0.75A@12V (standard 12V/1A) | |
USR-LG210-L-42: 1.25A@12V (standard 12V/2A) | ||
