The industrial Ethernet switch adopts high-performance imported switching chip to ensure the stable transmission of large traffic data, and supports 10/100/100M adaptive electrical port; Support -40~85℃ operating temperature, industrial power protection, indicator status display, guide rail/rack installation, fan-less thermal housing design, to achieve real readout, convenient and fast, but also meet the EMC4 level protection, IP40 protection, 6000V lightning protection and other indicators, can adapt to a variety of harsh industrial environment application needs.
● Support 2 Gigabit optical + 4 Gigabit electrical configuration
● Support -40 ~ 85 ℃ wide temperature work
● IP40 protection, EMC4 level protection, 6000V lightning protection
● Aluminum alloy shell, DIN rail mounting
● Supports dual power supply redundancy DC12~48V and single power supply AC85-264V/DC110-370V.
Technical Parameters | |
Protocol Standard | IEEE802.3(Ethernet), IEEE802.3u(100Base-TX&100Base-FX), IEEE802.3x (Flow control), IEEE802.3z(1000Base-LX)I, EEE802.3ab(1000Base-T) |
Switch Capability | |
MAC Table Size | 1k |
Switch Bandwidth | 14Gbps |
Switch Latency | <5μs |
Interface | |
Gigabit port | Number: 6 |
Connector: SFP Gigabit port(LC interface, single/multi-mode optional) or Gigabit RJ45 port | |
Baud rate: 1000Base-FX(SFP), auto-negotiation 10/100M-TX | |
Terminal block for relay alarm | 5.08mm terminal block, 1A@24VDC |
Terminal block for power input | 5.08mm terminal block |
Communication Distance | |
Twisted-pair | 100m(CAT5/CAT5e cable) |
Multi-mode fiber | Gigabit multi-mode: 850nm, 550m |
Single mode fiber | Gigabit single mode: 1310nm, 20km |
LED Indicator Lights | |
Front panel LED lights | Port light: LINK/ACT; SPEED |
Power status light: PWR1; PWR2 | |
Power | |
Input power | DC9-60V AD220V |
Power consumption | <3.5W@(MAX) |
Overload protection | support |
Inversed protection | support |
Working Environment | |
Operating temperature | -40°C~85°C |
Storage temperature | -45°C~85°C |
Ambient humidity | 5%~95% |
Physical Characteristics | |
Shell | IP40 protection, aluminum alloy shell |
Installation | Standard 35mm DIN-rail Mounting |
Dimension | 35mm*140mm*100mm |
Industry Standard | |
EMC | EN61000-4-2(ESD), Level 4 EN61000-4-3(RS), Level 4 EN61000-4-4(EFT), Level 4 EN61000-4-5(Surge), Level 4 EN61000-4-6(CS), Level 4 EN61000-4-8, Level 5 |
Impact | IEC60068–2-27 |
Falling | IEC60068-2-32 |
Shock | IEC60068-2-6 |
Warranty | |
Warranty | 5 Years |
Certification | CE, FCC, RoHS |
