The industrial Ethernet switch adopts high-performance imported switching chip to ensure the stable transmission of large traffic data, and supports 10/100/100M adaptive electrical port; Support -40~85℃ operating temperature, industrial power protection, indicator status display, guide rail/rack installation, fan-less thermal housing design, to achieve real readout, convenient and fast, but also meet the EMC4 level protection, IP40 protection, 6000V lightning protection and other indicators, can adapt to a variety of harsh industrial environment application needs.
● Support 1 Gigabit optical + 4 Gigabit electrical configuration
● Support -40 ~ 85 ℃ wide temperature work
● IP40 protection, EMC4 level protection, 4000V lightning protection
● Aluminum alloy shell, DIN rail type installation
● Adopt industrial-grade power supply design, a variety of power supply schemes are optional, to meet the user's flexible application
SPECIFICATION | |||||
model | ES205G-GF-4GT | ||||
web standard | IEEE802.3/802.3u/802.3x/802.3ab/802.3z | ||||
RJ45 port | 4 10Base-T/100Base-TX/1000Base-T | ||||
Fiber port | 1 1000Base-X | ||||
Fiber parameters | Wavelength: 850nm (multi-mode) 1310/1550nm (single-mode) Connector type: with shielded SFP base, LC interface Transmission distance: 10~80km optional (single-mode) 550m (multi-mode) Transmission rate: 1.25Gbps | ||||
power supply | DC: DC9-60V AC: AC85-264V/DC110-370V optional full load 3.7W(@24VDC) | ||||
Power consumption | Full load 3.7W (@24VDC) | ||||
exchange mode | store and forward | ||||
Backplane bandwidth | 10Gbps | ||||
ESD index | EN61000-4-2 Anti-static (ESD) Level 4: +8kV contact discharge, +15kV air discharge | ||||
Size | 118mmx86mmx35mm (excluding DIN rail and terminal block assembly size) | ||||
Operating temperature | -40°C~+85° | ||||
Certification | CCC , CE , FCC , RoHS | ||||
packing list | Network switch*1 Power cord*1 User Manual*1 | ||||
