The industrial Ethernet switch adopts high-performance imported switching chip to ensure the stable transmission of large traffic data, and supports 10/100/100M adaptive electrical port; Support -40~85℃ operating temperature, industrial power protection, indicator status display, guide rail/rack installation, fan-less thermal housing design, to achieve real readout, convenient and fast, but also meet the EMC4 level protection, IP40 protection, 6000V lightning protection and other indicators, can adapt to a variety of harsh industrial environment application needs.
● Support 100M optical + 2 100M electricity configuration
● support -40 ~ 85 ℃ wide temperature work
● IP40 protection, EMC4 level protection, 4000V lightning protection
● Aluminum alloy shell, DIN rail type installation
● Adopt industrial-grade power supply design, a variety of power supply schemes are optional, to meet the user's flexible application
SPECIFICATION | |
Model | ES203G-GF |
Network standard | ΙΕE802.3/802.3u/802.3x/802.3ab/802.3z |
R.J45 port | 2 10Base-T/100Base-TX/1000Base-T |
Fiber port | 1 1000Base-X |
Fiber parameters | Wavelength: 850nm (multimode) 1310/1550nm (single mode) Connector type: shielded SFP base, LC interface Transmission distance:10~80km optional (single mode) 550m (multi mode) Transmission rate: 1.25Gbps |
Power | DC: DC12-48V AC: AC85-264V/DC110-370V Optional |
Power consumption | full load 3.7W(@24VDC) |
Switch Mode | store and forward |
Backplane bandwidth | 6Gbps |
ESD index | EN61000-4-2 Anti-static (ESD) Level 4: +8kV contact discharge, +15kV air discharge |
Dimensions | 118mmx86mmx35mm (excluding DIN rail and terminal block assembly size) |
Operating temperature | 40°C~+85°C |
Certification | CCC , CE , FCC , RoSH |
packing list | Network switch*1 Power cord*1 User Manual*1 |
