The industrial Ethernet switch adopts high-performance imported switching chip to ensure the stable transmission of large traffic data, and supports 10/100/100M adaptive electrical port; Support -40~85℃ operating temperature, industrial power protection, indicator status display, guide rail/rack installation, fan-less thermal housing design, to achieve real readout, convenient and fast, but also meet the EMC4 level protection, IP40 protection, 6000V lightning protection and other indicators, can adapt to a variety of harsh industrial environment application needs.
● 10/100BaseT(X) (RJ45 Connector), 100BaseF(X) (Single/Multi-mode, SC/ST/FC Connector)
● IP40 Aluminum Alloy Shell with Fanless Design
● Industrial Grade Power Supply with Anti-revise/Overcurrent/Overvoltage/EMC Protection
● Working Temperature -40 to 85°C
● Satisfy Harsh Industrial Environment
Technical Parameters | |
Protocol Standard | IEEE802.3, IEEE802.3u (100Base-TX&100Base-FX), IEEE802.3x (Flow control) |
Switch Capability | |
MAC Table Size | 1k |
Switch Latency | <5μs |
Packet Cache | 448Kbit |
Switch Bandwidth | 1Gbps |
Interface | |
100M port | Number: 4 |
Connector: 1×9 fixed fiber port(single/multi-mode optional, SC/FC/ST interface) or RJ45 100Base-TX port | |
Baud rate:100Base-FX(Fiber port),10/100M-TX auto-negotiation | |
Terminal block for power input | 5.08mm terminal block |
Communication Distance | |
Twisted-pair | 100m(CAT5/CAT5e cable) |
Multimode fiber | 100M multimode: 1310nm, 2km |
Single mode fiber | 100M single mode:1310nm, 20/40km; 1550nm; 60/80km |
LED Indicator Lights | |
Front panel LED lights | Port light: LINK/ACT; SPEED; RUN |
Power status light: PWR1/PWR2 | |
Power | |
Input power | DC9~60V AD220V |
Power consumption | 1.5W@24V |
Overload protection | support |
Inversed protection | support |
Working Environment | |
Operating temperature | -40°C~85°C |
Storage temperature | -40°C~85°C |
Ambient humidity | 5%~95% |
Physical Characteristics | |
Shell | IP40 protection, aluminum alloy shell |
Installation | Standard 35mm DIN-rail Mounting |
Dimension | 33.0mm*114.0mm*80.0mm |
Industry Standard | |
EMC | EN61000-4-2(ESD), Level 4 EN61000-4-3(RS), Level 4 EN61000-4-4(EFT), Level 4 EN61000-4-5(Surge), Level 4 EN61000-4-6(CS), Level 4 EN61000-4-8, Level 5 |
Impact | IEC60068-2-27 |
Falling | IEC60068-2-32 |
Shock | IEC60068-2-6 |
Warranty | |
Warranty | 5 Years |
Certification | CE, FCC, RoHS |
