Relays
REL-MR-12DC/21HC AU
REL-MR-12DC/21HC AU
Subscribe to get pricesModel: REL-MR-12DC/21HC AU
Order No: 2961532
SKU: 1742372145887460920
Condition: New Sealed Under Guarantee
Size: 25.00 mm，12.70 mm，29.00 mm
Weight: 17.00g
Product Selection Engineer：ChuFuHua
In Stock
Brief Introduction
REL-MR-12DC/21HC AU
Product type: Single relay, product family 3RH11.Electrical characteristicsInput Data: The input voltage is rated at 12V DC and the input voltage range is from 7.8V DC to 28.8V DC. The drive is monostable and non-polarized, with a typical input current of 33mA, a typical response time of 7ms, a typical release time of 3ms, and a coil resistance of 360Ω ±10% at 20°C at the rated input voltage. The protection circuit is a freewheeling diode and the status is shown as a yellow LED.
