Brief Introduction

REL-MR-24AC/21-21AU

Product type: Single relay, miniature power relay with plug-in connection, multi-layer gold-plated contacts, 2 changeover contacts (2PDT).Electrical characteristicsInput data: Rated input voltage is 24V AC and power supply frequency is 50/60Hz. Typical input currents are 32mA at 50Hz, 24mA at 60Hz at rated input voltage. Typical response times are 3ms - 12ms (phase dependent), typical release time ranges are 2ms - 9ms (phase dependent), coil resistance is 350Ω±10% at 20°C, and power consumption is 0.77W under spection.Output data: Under normal conditions, the maximum switching voltage is 30V AC, 36V DC, the minimum switching voltage is 100mV (at 10mA), the minimum switching current is 1mA (at 24V), the maximum inrush current and the limiting continuous current are both 50mA, and the maximum power rating (resistive load) is 1.2W (24V DC). When the gold plating layer is destroyed, the maximum switching voltage is 250V AC/DC, the minimum switching voltage is 5V (at 100mA), the limited continuous current is 8A, the maximum impulse current is 50A (20ms), and the minimum switching current is 10mA (at 5V), and the maximum power rating value (resistance load) will change accordingly, such as 190W (24V DC), 85W (48V DC), 60W (60V DC), 44W (110V DC), 60W (220V DC), 2000VA（250V AC）。 The switching capacitances are 2A (at 24V, DC13), 0.2A (at 110V, DC13), 0.2A (at 250V, DC13), 2A (at 24V, AC15), 2A (at 120V, AC15), 2A (at 250V, AC15).
