Brief Introduction

MDX61B0014-5A3-4-0T

Basic parametersInput: 3-phase 380 - 500V, 50/60Hz, 3.6A.Output: 2.8kVA, 4A, 1.5kW motor.Voltage range: Operates reliably in the bus voltage range of 3-phase 380 - 480V (-15% / 10%).Ambient temperature: Ambient temperatures up to 60°C during operation.Control functionsControl mode: support VVVF speed regulation (variable voltage and frequency speed regulation, U/F = constant) and vector control, which can theoretically divide the stator current current of the asynchronous motor into the current component that generates the magnetic field (magnetic field current) and the current component that generates torque (torque current), so as to achieve high-precision motor control.Built-in functions: Integrated IPOS positioning and sequencing control system as standard for specific control tasks and logic operations. The application version of the inverter logo ends with "0T", which provides the interface to the application module, and the standardized control program in the application module is specially used for positioning, curling and control drive tasks, the user only needs to enter the parameters required by the application, and the parameters can be set through the wizard without complex programming.Energy-saving featuresECO Mode: Built-in energy-saving mode for V/f and V2/f control, which saves energy by automatically adjusting the magnetic flux current. The drives also support the display of energy consumption values in kWh, CO2 and even local units.DC co-linkage: SINAMICS V20 frequency inverters with the same power rating can share the same DC bus, enabling energy reuse and reducing the need for energy-intensive braking and external components.
